Scangrip UV Extreme Plus
$3,347.00
(+$30.00 US Shipping)The UV Extreme Plus is the next evolution in professional UV curing, offering the same powerful performance and fast one-minute cure time as the original UV Extreme—but with enhanced usability and efficiency for everyday production work. It features a wide elliptical beam that covers large surfaces like hoods, bumpers, and fenders with ease, helping shops move faster and reduce bottlenecks in the prep and paint process.
Built for controlled environments, the UV Extreme Plus is lighter and easier to position without sacrificing power. Its compact form, long-life LED output, and zero heat generation make it an ideal solution for high-volume body shops that prioritize productivity and workflow speed. With a large curing area and efficient energy use, the Plus model delivers all the performance you expect—optimized for streamlined operation.
Scangrip UV Extreme Plus
The Scangrip UV Extreme Plus is the most advanced LED UV curing light available, delivering unmatched power and coverage for high-speed curing over large paint repair areas—up to 135 x 130 cm, equivalent to the size of a full car door.
Up to 6x more powerful than traditional UV lights, the UV Extreme Plus utilizes active cooling to maximize output in a compact, rugged design. Whether you’re curing UV primers, fillers, or coatings, this system delivers faster results and greater efficiency than ever before.
UV Extreme Plus – Key Features
- 1-minute cure time for UV primers and fillers
- Large elliptical beam covers up to 2,015 in² for efficient panel curing
- Consistent UV output with zero heat generation—safe for plastic components
- Long-lasting UV LED with over 30,000 hours of service life
- Optimized 395–400 nm wavelength for automotive refinishing materials
- Lightweight and portable design for easy positioning in the shop
- Passive cooling system—no fans, no maintenance
- Compatible with SCANGRIP Tripod and Wheel Stand for flexible mounting
- Includes a 16′ 4″ heavy-duty cable with SCHUKO plug
- Designed for professional use in controlled, high-throughput environments
Documentation
Scangrip UV Extreme Plus Product Specs
UV Extreme Plus – Full Specifications
- Beam Type: Elliptical (uniform UV distribution)
- Curing Area:
- 2,015 in² at 32″ distance
- 1,330 in² at 16″ distance
- 99 in² at 4″ distance
- UV Wavelength Range: 395–400 nm
- Power Consumption: 600 W
- Operating Voltage (AC): 220–240 V
- LED Lifetime: >30,000 hours
- Cable: 16 ft. 4 in. / 2×AWG 17 H05RN-F / SCHUKO plug
- Dimensions: 16 5/16″ × 9 1/2″ × 6 5/16″
- Net Weight: 15 lb 8 oz (7.0 kg)
- Protection Rating: IP30
- Impact Protection: IK06
- Impact Resistance: Drop-tested to 3 feet (1 meter)
- Operating Temperature Range: 14°F to 104°F (–10°C to 40°C)
- Cooling Method: Passive (fanless)
- Mounting Compatibility: SCANGRIP Tripod, SCANGRIP Wheel Stand
- Certifications: CE compliant
- Housing Material: Durable aluminum and composite construction
- Heat Generation: None—safe for temperature-sensitive substrates
Usage Recommendations
- Distance: Use at 16″–32″ for optimal curing coverage.
- Cure Time: Typical cure is 1 minute; follow material guidelines.
- Ideal For: Large panels like doors, bumpers, and hoods.
- Mounting: Use with SCANGRIP Tripod or Wheel Stand.
- Environment: Indoor use only, 14°F–104°F range.
- Safety: Wear UV eye protection; avoid direct beam exposure.
- Maintenance: Dry wipe only; inspect cable and housing regularly.
